Eternergy’s engineering design capabilities cover Primary, Secondary, and SCADA systems for HV and EHV substations. We apply standardized yet flexible design templates combined with innovative engineering practices to optimize substation layouts, reduce equipment footprint, and improve system reliability and operability.

Our integrated design approach ensures seamless coordination between electrical primary equipment, protection and control systems, and SCADA automation, resulting in efficient, safe, and future-ready substation solutions.

Engineering Design

Primary design

Basis of design, Specifications, and equipment data sheet
Support Structures, Gantries and Poles
Equipment Sizing
Substation primary plant equipment specifications
Earthing works and foundation Design
Insulation Coordination

Primary Schematics
Electromagnetic Interference
Control & switch room buildings
UPS and DC batteries
Cable design & rating studies
Lightning Protection

Basis of Design & Specifications
Secondary drawings
Protection Engineering design
Protection Conceptual design
CT/VT sizing
Protection Logic design
Fault Studies
Coordination Study
Protection setting report
Protection Setting Calculations
Protection relay configurations
BoMs & Cable Schedules

Secondary design

SCADA design

Basis of Design & Specifications
HMI/SCADA System Configurations
DCS, PLC, RTU Configurations
TCP/IP, Ethernet/IP, Modbus, DNP3, IEC61850 etc Configurations
Remote/Network Terminal Unit
Remote Input/output
IED configuration across various protocols
